2CT cartridge design for boring heads size 68.

3CT cartridge design for boring heads sizes 85, 100, 200, 300, 400 and 500.

All cartridges have a socket set adjusting screw that allows the radial adjustment of the cartridge over the boring head's slide block. In rough boring heads (twin adjustable boring heads) this radial adjustment also allows setting the symmetrical position of the two cutting insert edges.

Cartridges available in 75º, 90º and other cutting approach angles.

Cartridges available in different insert geometries (CC.., CN.., DC.., SC.., TC.., TP.., WC.., etc.).

Change to different insert style or approach angle by simply exchanging the cartridge.

Available in pairs for symmetric or axial staggered insert set-up:

Both inserts cut on the same radial and axial plane. Radial stagger is possible by off-setting one cartridge.

One of the two cartridges is 0.5 mm higher. The insert in this cartridge cuts axially ahead of the other. By setting it radially in a smaller diameter it performs the roughing duty in a first step. The other cartridge with its insert set radially to full diameter performs the finishing duty.
